RFID NXP HITAG® S256 / S2048 Card
SizeCR80--85.5*54mm (Be customized)
CraftGlossy, Matte, Matte, Epoxy (Single or Double), Brushed (Single or Double), Laser (Single or Double)
Thickness0.76mm / 0.84mm / or be customized
MaterialRPVC/PLA/PC/PET/PETG/PBAT/TESLIN
Printing methodLaser code, flat code (gold flat code, white flat code, black flat code), inkjet code (ordinary inkjet code, UV inkjet code), embossed code (gold embossed code, silver embossed code), barcode (one-dimensional barcode, two-dimensional code barcode), QR code
Frequency13.56MHz
Chips
NXP HITAG® S256
NXP HITAG® S2048

HITAG 1 based transponders are highly integrated and do not need any additional components beside the external coil.


Data between Key (RWD) and transponder is transmitted bidirectionally, in Half Duplex Mode. The HITAG 1 transponder IC offers also an encrypted data transmission.



Features

Integrated Circuit for Contactless Identification Transponders and Cards

Integrated resonance capacitor of 210 pF with 5 % tolerance over full production

Frequency range 100 kHz to 150 kHz.


Target Applications

Animal Identification

Laundry Automation

Beer keg and gas cylinder logistic

Pigeon Race Sports

Brand Protection Applications



FAQ
Optional materials
PVC/PET/PETG/PLA/PBAT/RPVC/WOODEN/TESLIN/PC
